14.4W 60 RGB LED Strips Lights 12V 120 Degree Beam Angle IP20 RGB LED Strip Lights

14.4W 60 RGB LED Strips Lights 12V 120 Degree Beam Angle IP20 RGB LED Strip Lights

    • 14.4W 60 RGB LED Strips Lights 12V 120 Degree Beam Angle IP20 RGB LED Strip Lights
    • 14.4W 60 RGB LED Strips Lights 12V 120 Degree Beam Angle IP20 RGB LED Strip Lights
    • 14.4W 60 RGB LED Strips Lights 12V 120 Degree Beam Angle IP20 RGB LED Strip Lights
  • 14.4W 60 RGB LED Strips Lights 12V 120 Degree Beam Angle IP20 RGB LED Strip Lights

    Product Details:

    Place of Origin: China
    Brand Name: LEDCORP
    Certification: ISO9001, CE / RoHS
    Model Number: LC60-N5050-RGB

    Payment & Shipping Terms:

    Minimum Order Quantity: 100meters/20reels
    Price: negotiation
    Packaging Details: Anti-Static Pack, 12KG/Carton
    Delivery Time: 15 working days
    Payment Terms: T/T , PayPal
    Supply Ability: 500,000mters per month
    Contact Now
    Detailed Product Description
    Led: 5050 Qty/m: 60 LEDs/m
    Voltage: 12/24V Power: 14.4 W/m
    Color: RGB Controller: RGB Controller
    Packing: 5 M/roll Angle: 120°
    PCB: 10mm IP: IP20-68
    Certification: UL/CE/RoHS Lifespan: >35000 Hrs
    Warranty: 3 Yrs Weight: 0.2 Kg/roll

    14.4W 60LED 5050 RGB LED Strips Lights 12/24V                14.4W 60 RGB LED Strips Lights 12V 120 Degree Beam Angle IP20 RGB LED Strip Lights  5050 60 RGB.pdf

    14.4W 60 RGB LED Strips Lights 12V 120 Degree Beam Angle IP20 RGB LED Strip Lights

    14.4W 60 RGB LED Strips Lights 12V 120 Degree Beam Angle IP20 RGB LED Strip Lights





    RGB 5050 60LED is 5m long flexible strip with5050SMD 300LED as source, 10/12mm white PCB (2Oz) in 12V, 10mm white PCB (2Oz) in 24V, from IP20 to IP68 rated with 3M or clips mounted easily.



    Application area:



    1. Architectural decorative lighting
    2. Archway, canopy & bridge edge lighting
    3. Amusement park, theater & aircraft cabin mood lighting
    4. Emergency hallway lighting
    5. Auditorium walkway lighting.
    6. Stairway accent lighting
    7. Concealed lighting
    8. Backlighting for signage letters
    9. Cove lighting



    Product advantages:



    1. More Lumens per watt

    2. Less Lumens depreciation, <0.3% in 1000h, <3% in 10000h

    3. No faulty of LEDs, 0% in 10000h

    4. Uniform light, even light output

    5. Consistent light color of LEDs

    6. Consistant brightness from the front to the end




    Technical details:



    Details

    Item

    Unit

    Specification

    Physical data

    LED type

    SMD

    5050SMD

    LED Qty /meter

    LED/m

    60

    Dimensions

    mm

    10*2*5000 (W*H*L)

    Type of protection

    IP

    IP20 / IP65

    Working temperature

    °C

    0-40°C

    Electrical data

    Power

    w/m

    14.4

    Voltage

    VDC

    12 (24 option)

    Optical data





    Beam angle

    degrees

    120

    Light color



    RGB

    Color BINs





        Wave Length

    nm

    Red : 619 - 635 nm

    Green : 510 - 530 nm

    Blue : 460 - 480 nm

    Color rendering index

    CRI

    70-90

    Order reference

    HS code

    94054090

    Part. no

    LC60-N5050-RGB-IP20-12/24

    LC60-W5050-RGB-IP65-12/24

    LC60-W5050-RGB-IP68-12/24





    Dimension:

    14.4W 60 RGB LED Strips Lights 12V 120 Degree Beam Angle IP20 RGB LED Strip Lights

    14.4W 60 RGB LED Strips Lights 12V 120 Degree Beam Angle IP20 RGB LED Strip Lights

    14.4W 60 RGB LED Strips Lights 12V 120 Degree Beam Angle IP20 RGB LED Strip Lights

    Installation:

                       14.4W 60 RGB LED Strips Lights 12V 120 Degree Beam Angle IP20 RGB LED Strip Lights

    Packing details:



    Part No.

    HS code

    Packaging unit

    meters per box

    reels per box

    Dimensions(mm) LxWxH

    Gross weight

    Volume(cbm)

    LC60-N5050-RGB-IP20

    94054090

    One Pack

    5m

    1reel

    150*150*12

    0.11kg

    0.00027

    Shipping  box

    250m

    50reel

    500*350*250

    12kg

    0.04375

    LC60-W5050-RGB-IP65

    94054090

    One Pack

    5m

    1reel

    220*220*13

    0.22kg

    0.00063

    Shipping  box

    100m

    20reel

    500*350*250

    12kg

    0.04375
